TPE BONDING FOR MEDICAL DEVICES

BONDING THERMOPLASTIC ELASTOMERS (TPE) & CONNECTORS IN MEDICAL DEVICES

Design engineers choose TPEs for high degree of purity (low extractable), recycling ability and cost-effectiveness. It is also a safer product to use over latex and PVC. Coupled with enhanced grip performance, improved ergonomics, improved aesthetics, and critical impact protection and impermeability to air and moisture, it is an obvious winner over the conventional use of PVCs as the preferred choice. The biggest challenge to wide-spread switch to TPEs is due to their low surface energy for bonding applications. Incure now delivers solution to this bonding problem with newly developed Cyro-Weld series of medical adhesives for disposable medical devices.

Advantages of Cyro-WeldTM - UV Medical Adhesives

  Cure In Seconds!
  High Bonding Strength
  Solvent Free
  Tack-Free
  Wide Range of Viscosities


Learn about our Light Curing Systems
C9000 / U8000 UV Light Curing Conveyor Systems
F100P / F200P Programmable UV Flood Curing Lamps
L1000 High Intensity UV LED Flood Lamps
L9000 Compact UV LED Spot Curing Lamps
S10 / S20 Ultra High Intensity Light-Curing Spot Lamps
Cyro-WeldTM Series Core Products
Product Product Highlights Color Viscosity Tensile Hardness Elongation
5480 Very low viscosity, high-strength medical grade PC / TPE bonder with enhanced temperature and moisture resistance. Formulated to meet ISO 10993-5.
Slight Yellowish Tint, Clear 75 cP 1,800 – 5,500 psi D40 - D50 700%
5300F Low viscosity, multi-substrate bonder for most plastics, metal and glass. Ideal for needle / reservoir / catheter / transducer assemblies in the medical industry. Formulated to meet ISO 10993-5. Passes EtO & gamma sterilization.
Translucent

105 cP 2,700 – 5,300 psi D73 - D83  '8%
5021F Low viscosity, multi-substrate bonder for most plastics, metal and glass. Ideal for needle / reservoir / catheter / transducer assemblies in the medical industry. Formulated to meet ISO 10993-5. Passes EtO & gamma sterilization.
Clear, Fluorescing  150 cP 4,200 - 7,000 psi D68 - D78 82%
5422F Low viscosity, multi-substrate bonder for most plastics, metal and glass. Ideal for needle / reservoir / catheter / transducer assemblies in the medical industry. Meet ISO 10993-5. Passes EtO & gamma sterilization.  Clear, Fluorescing 300 cP 3,700 - 6,900 psi D57 - D67 350%
5463 Low viscosity, high-strength medical grade PC / TPE bonder with enhanced temperature and moisture resistance. Formulated to meet ISO 10993-5.
Slight Yellowish Tint, Clear 700 cP 1,600 - 6,700 psi D27 - D37 280%
5422T Medium viscosity, multi-substrate bonder for most plastics, metal and glass. Ideal for needle / reservoir / catheter / transducer assemblies in the medical industry. Formulated to meet ISO 10993-5. Passes EtO & gamma sterilization.
Clear 5,000 cP 4,000 - 7,000 psi D60 - D70  350%
5422VT High viscosity, multi-substrate bonder for most plastics, metal and glass. Ideal for needle / reservoir / catheter / transducer assemblies in the medical industry. Formulated to meet ISO 10993-5. Passes EtO & gamma sterilization.
Clear Translucent  11,000 cP  4,800 - 7,100 psi D63 - D73 320%
5459 Bonding gel. Multi-substrate bonder for most plastics, metal and glass. Ideal for needle / reservoir / catheter / transducer assemblies in the medical industry. Formulated to meet ISO 10993-5. Passes EtO & gamma sterilization.  Clear

53,000 cP  3,700 - 6,900 psi D63 - D73  260%
Above products are available in other Viscosities versions: T (Thick), VT (Very Thick), G (Gel), S (Special Viscosity)
Package Size: 10 ml syringe / 30 ml syringe / 1 kg Bottle
