UV SILICONE

UV SILICONE

Incure Pyra-SilTM range of UV Cure Silicones are designed for high volume production where applications require fast setting. Depending on application, typical full cure can be achieved within 24hours after UV cure.The secondary moisture cure feature enables full curing in shadowed areas.

These fast settting UV cure silicone adhesives are available in various viscosity for both manual and automatic dispensing equipment. Formulated with fluorescing properties to allow for quick visual inspection of coating coverage,it is ideal for both in-line visual inspection and outgoing QA sampling checks.


Advantages of Incure's Pyra-SilTM UV Cure Silicone

• Single Component – No Mixing Required
• Cures Tack Free
• Adhesion to Most Substrates - Glass, Plastics & Metals
• Fluorescent for In-Line Detection
• Resist Temperatures to 260°C
• Fast Processing Speed for Automated Assembly
• Excellent Environmental Resistance

Learn about our Light Curing Systems

C9000 / U8000 UV Light Curing Conveyor Systems
F100P / F200P Programmable UV Flood Curing Lamps
L1000 High Intensity UV LED Flood Lamps
L9000 Compact UV LED Spot Curing Lamps
S10 / S20 Ultra High Intensity Light-Curing Spot Lamps
  Overview of Product Spectrum
 Product  Product Highlights  Cure Time  Viscosity  Temp. Resistance  Color  Tensile
        °C

psi

901



 One-part UV / Moisture cure, high temperature multi-substrates silicone for component coating / sealing. Takes care of uncured adhesive in shadowed areas. 24 hr, RT 7,000 -45 to 260 Clear 100

904



 One-part UV / Moisture cure, high temperature multi-substrates silicone adhesive. Takes care of uncured adhesive in shadowed areas.Used as form-in-place  gaskets (FIPG), conformal coating and sealant. 24 hr, RT 2,500 -45 to 260 Clear 80

905



 One-part UV / Moisture cure, high temperature multi-substrates silicone adhesive. Takes care of uncured adhesive in shadowed areas. Used as conformal coating and sealant for PCBA and electronic components. 24 hr, RT 600 -45 to 260 Clear 100

909



 One-part UV / Moisture cure, high temperature multi-substrates silicone adhesive. Takes care of uncured adhesive in shadowed areas.Used as form-in-place  gaskets (FIPG), conformal coating and sealant. 72 hr, RT 3,000 -45 to 260 Clear 100

915



 One-part UV / Moisture cure, high temperature multi-substrates silicone adhesive. Takes care of uncured adhesive in shadowed areas.Used as form-in-place gaskets (FIPG), conformal coating and sealant. 72 hr, RT 100,000 -45 to 260 Straw 500

917



 One-part UV / Moisture cure, high temperature multi-substrates silicone adhesive. Takes care of uncured adhesive in shadowed areas.Used as form-in-place gaskets (FIPG), conformal coating and sealant. 72 hr, RT 45,000 -45 to 260 Straw 200
Packaging Size: 1 Oz. Tube, 3 Oz. Tube, 300ml Cartridge, 40lb. Pail
