Quad-cureTM Series Core Products (Glass, Crystals) |
| |
Product |
Product Highlights |
|
Substrates |
Color |
Viscosity |
Tensile (psi) |
Hardness |
Elongation |
| |
1931 |
Cures with UV / Visible / Heat or activator (Actif 398). Very low viscosity, high strength metal / glass / ceramics bonder. Low linear shrinkage, good weather-ability, temperature and moisture resistance.
|
|
High Performance
Metal/Glass/Ceramics |
Slight Tint |
130 cP |
7,400 – 10,000 |
D75 – D85 |
4% |
| |
1933 |
Very low Viscosity, UV / Visible light / LED / Heat-curing, high strength metal-glass bonder. Track free,used in very high strength bonding application requiring good temperature and moisture resistance.
|
|
High Strength
Metal/Glass/Ceramics |
Slight
Translucent |
700 cP |
8,300 – 14,000 |
D80 – D90 |
33% |
| |
Quad-cureTM Series Core Products (Glass + Metal) |
| |
Product |
Product Highlights |
|
Substrates |
Color |
Viscosity |
Tensile (psi) |
Hardness |
Elongation |
| |
9254 |
Cures with UV / Visible / Heat or Actif 398. Very high strength, medium viscosity metal / glass bonder. Low shrinkage and good passive vibration isolation capability. Resistant to moisture and low water absorption
|
|
High Performance
Metal/Glass/Ceramics |
Slight Tint |
1,850 cP |
16,000 - 9,500 |
D66 – D76 |
60% |
| |
9263 |
Cures with UV / Visible / Heat or Actif 398. Very high strength, low viscosity metal / glass bonder. Low shrinkage and good passive vibration isolation capability. Resistant to moisture and low water absorption.
|
|
High Performance
Metal/Glass/Ceramics |
Slight Tint |
750 cP |
6,500 - 16,000 |
D67 – D77 |
510% |
| |
9245 |
Cures with UV / Visible / Heat or Actif 398. Very high strength, high viscosity metal / glass bonder. Low shrinkage and good passive vibration isolation capability. Resistant to moisture and low water absorption.
|
|
High Performance
Metal/Glass/Ceramics |
Slight Tint |
3,650 cP |
6,800 - 10,000 |
D65 – D75 |
820% |
| |
MG |
Cures with UV / Visible / Heat or Actif 398. Very high strength, high viscosity metal / glass bonder. Low shrinkage and good passive vibration isolation capability. Resistant to moisture and low water absorption.
|
|
Multi-Substrates
(Plastics) |
Clear Transparent |
1,400 cP |
390- 8,900 |
D75 – D85 |
76% |
| |
1922 |
Cures with UV / Visible / Heat or activator (Actif 398). Low viscosity and high strength metal / glass / ceramics bonder. Very low shrinkage and good weather-ability, temperature and moisture resistance.
|
|
High Performance
Metal/Glass/Ceramics |
Slight Tint |
375 cP |
9,700 - 10,900 |
D77 – D87 |
4% |
| |
Uni-WeldTM Series Core Products (Glass + Metal + Plastic) |
| |
Product |
Product Highlights |
|
Substrates |
Color |
Viscosity |
Tensile (psi) |
Hardness |
Elongation |
| |
1203 |
Cures tack-free with up to 5,400 PSI on many different metals / glass / ceramics. Very low linear shrinkage with enhanced excellent moisture and temperature resistance. Good passive vibration isolation capability.
|
|
Metal/Glass/Ceramics |
Clear |
300 cP |
4,400 – 5,400 |
D59 – D69 |
400% |
| |
1238 |
Very high strength, high viscosity metal / glass bonder. Very low water absorption and linear shrinkage. Fast-curing and ideal for bonding all types of glass panels to stainless steel structures in general industries.
|
|
High Strength
Metal/Glass/Ceramics |
Clear Transparent |
22,000 cP |
390- 8,900 |
D75 – D85 |
76% |
| |
1471 |
Industrial grade, very low viscosity high strengthmulti-substrate bonder. Very useful for bonding of substrates with different hardness. |
|
Multi-Substrates
(High Strength Plastics) |
Clear
Translucent |
250 cP |
2,400 - 6,800 |
D68 – D78 |
310% |
| |
Package Size: 10 ml syringe / 30 ml syringe / 30 ml squeeze bottle / 100 ml squeeze bottle / 250 ml squeeze bottle / 1 kg Bottle / 1 Gallon Pail / 2 Gallon Pail / 5 Gallon Pail |
Cure In Seconds!
