GLASS / GLASS - METAL

UV GLASS BONDING ADHESIVES FOR GLASS & INDUSTRIAL ASSEMBLY

Incure glass glue cure in seconds upon exposure to UV light. These cutting edge UV light-curing adhesives are particularly designed for decorative and industrial glass assembly. Suitable for glass to glass, glass to metal, glassware bonding, acrylic glass, crystals, tempered glass, etc.



Advantages of Quad-CureTM - UV Glass Adhesives

  Cure In Seconds!
  Invisible Bond
  Excellent Adhesion
  Environmetally Resistant
  Superior Performance
Learn about our Light Curing Systems

C9000 / U8000 UV Light Curing Conveyor Systems
F100P / F200P Programmable UV Flood Curing Lamps
F500 Portable UV Curing Lamps
L9000 Compact UV LED Spot Curing Lamps
S10 / S20 Ultra High Intensity Light-Curing Spot Lamps
  Quad-cure™ Series Core Products (Glass, Crystals)
  Product Product Highlights   Substrates Color Viscosity Tensile (psi) Hardness Elongation
  1931 Cures with UV / Visible / Heat or activator (Actif 398). Very low viscosity, high strength metal / glass / ceramics bonder. Low linear shrinkage, good weather-ability, temperature and moisture resistance.
  High Performance
Metal/Glass/Ceramics
Slight Tint 130 cps 7,400 – 10,000 D75 – D85 4%
  1933 Very low Viscosity, UV / Visible light / LED / Heat-curing, high strength metal-glass bonder. Track free,used in very high strength bonding application requiring good temperature and moisture resistance.
  High Strength
Metal/Glass/Ceramics
Slight
Translucent
700 cps  8,300 – 14,000  D80 – D90 33%
  Quad-cure™ Series Core Products (Glass + Metal)
  Product Product Highlights   Substrates Color Viscosity Tensile (psi) Hardness Elongation
  9254 Cures with UV / Visible / Heat or Actif 398. Very high strength, medium viscosity metal / glass bonder. Low shrinkage and good passive vibration isolation capability. Resistant to moisture and low water absorption
  High Performance
Metal/Glass/Ceramics
Slight Tint 1,850 cps 16,000 - 9,500 D66 – D76 60%
  9263 Cures with UV / Visible / Heat or Actif 398. Very high strength, low viscosity metal / glass bonder. Low shrinkage and good passive vibration isolation capability. Resistant to moisture and low water absorption.
  High Performance
Metal/Glass/Ceramics
Slight Tint 750 cps 6,500 - 16,000 D67 – D77  510%
  9245 Cures with UV / Visible / Heat or Actif 398. Very high strength, high viscosity metal / glass bonder. Low shrinkage and good passive vibration isolation capability. Resistant to moisture and low water absorption.
   High Performance
Metal/Glass/Ceramics
Slight Tint 3,650 cps  6,800 - 10,000 D65 – D75  820%
  MG Cures with UV / Visible / Heat or Actif 398. Very high strength, high viscosity metal / glass bonder. Low shrinkage and good passive vibration isolation capability. Resistant to moisture and low water absorption.
  Multi-Substrates
(Plastics)
Clear Transparent 1,400 cps  390- 8,900 D75 – D85  76%
  1922 Cures with UV / Visible / Heat or activator (Actif 398). Low viscosity and high strength metal / glass / ceramics bonder. Very low shrinkage and good weather-ability, temperature and moisture resistance.
  High Performance
Metal/Glass/Ceramics
Slight Tint 375 cps 9,700 - 10,900 D77 – D87 4%
  Uni-Weld™ Series Core Products (Glass + Metal + Plastic)
  Product Product Highlights   Substrates Color Viscosity Tensile (psi) Hardness Elongation
  1203 Cures tack-free with up to 5,400 PSI on many different metals / glass / ceramics. Very low linear shrinkage with enhanced excellent moisture and temperature resistance. Good passive vibration isolation capability.
  Metal/Glass/Ceramics Clear 300 cps 4,400 – 5,400 D59 – D69 400%
  1238 Very high strength, high viscosity metal / glass bonder. Very low water absorption and linear shrinkage. Fast-curing and ideal for bonding all types of glass panels to stainless steel structures in general industries.
  High Strength
Metal/Glass/Ceramics
Clear Transparent 22,000 cps 390- 8,900 D75 – D85 76%
  1471 Industrial grade, very low viscosity high strengthmulti-substrate bonder. Very useful for bonding of substrates with different hardness.   Multi-Substrates
(High Strength Plastics)
Clear
Translucent
250 cps 2,400 - 6,800 D68 – D78 310%
  Package Size: 10 ml syringe / 30 ml syringe / 30 ml squeeze bottle / 100 ml squeeze bottle / 250 ml squeeze bottle / 1 kg Bottle / 1 Gallon Pail / 2 Gallon Pail / 5 Gallon Pail
